Digital Power Meter 66203/66204 User’s Manual
5-34
Setting syntax: HOLD:TIME<space><NR1><PMT>
Setting parameters: <NR1>, 0 ~ 9999
Query syntax: HOLD:TIME?[<space><MAX | MIN>]<PMT>
Return parameters: <NR1>, 0 ~ 9999
Header on: :HOLD:TIME<space><NR1><RMT>
Header off: <NR1><RMT>
Example: none
[CONFigure:]DISPlay:UPDate
Type: System.
Description: This command sets the screen display update rate.
Setting syntax: DISPlay:UPDate<space><NR1><PMT>
Setting parameters: <NR1>, 0 ~ 3, 0: 0.25s, 1: 0.5s, 2: 1s, 3: 2s
Query syntax: DISPlay:UPDate?<PMT>
Return parameters: <NR1>, 0.25 | 0.5 | 1 | 2
Header on: :DISPlay:UPDATE<space><NR1><RMT>
Header off: <NR1><RMT>
Example: none
[CONFigure:]DISPlay:BRIGHt
Type: System.
Description: This command sets the bright of screen.
Setting syntax: DISPlay:BRIGHt<space><CRD><PMT>
Setting parameters: <CRD>, LOW | MIDDLE | HIGH
Query syntax: DISPlay:BRIGHt?<PMT>
Return parameters: <CRD>, LOW | MIDDLE | HIGH
Header on: :IDISPLAY:BRIGHT<space><CRD><RMT>
Header off: <CRD><RMT>
Example: none
[CONFigure:]INPut:WIRing
Type: Three-Phase.
Description: This command is used to switch the input wiring mode.
Setting syntax: INPut:WIRing<space><NR1><PMT>
Setting parameters: <NR1>, 0 ~ 3, 0: 1P2W, 1: 1P3W, 2: 3P3W, 3: 3P4W
Query syntax: INPut:WIRing?<PMT>
Return parameters: <CRD>, 1P2W | 1P3W | 3P3W | 3P4W
Header on: :INPut:WIRING<space><CRD><RMT>
Header off: <CRD><RMT>
Example: none
[CONFigure:]INPut:CT
Type: Channel-Specific or All channels.
Description: This command is used to switch the CT function.
Setting syntax: INPut:CT<space><CRD><PMT>
INPut:CT<space><CRD>,<CRD>,<CRD>,<CRD><PMT>
Setting parameters: <CRD>, OFF | ON, ‘/’:denote no action
Query syntax: INPut:CT?<PMT>
Return parameters: <CRD>, OFF | ON
Header on: :INPut:CT<space><CRD>,<CRD>,<CRD>,<CRD><RMT>
