Chroma 66204 - Trigger & Protection Commands; Trigger Control

Digital Power Meter 66203/66204 User’s Manual
5-36
,<NR2><RMT>
Header off: <NR2>,<NR2>,<NR2>,<NR2><RMT>
Example: none
TRIGger
Type: Channel-Specific or All channels.
Description: Three different modes, GONG, INRUSH and ENERGY, are
triggered by this command.
Setting syntax: TRIGger<space><CRD><PMT>
Setting parameters: <CRD>, OFF | ON
Query syntax: TRIGger?[<space><NR1>]<RMT>
Query parameters: <NR1>, 1 ~ 4: CH1 ~ CH4, 0 : All Channels
Return parameters: <CRD>, STOP | FINISH | RUNNING
When query parameter set to 1 ~ 4 :
Header on: :TRIGGER<space><CRD><RMT>
Header off: <CRD><RMT>
When query parameter set to 0:
Header on: :TRIGGER<space><CRD>,<CRD>,<CRD>, <CRD><RMT>
Header off: <CRD>,<CRD>,<CRD>,<CRD><RMT>
Example: none
TRIGger:MODE
Type: All channels.
Description: This command is used to select which mode will be triggered.
Setting syntax: TRIGger:MODE<space><CRD><PMT>
Setting parameters: <CRD>, NONE | GONG | INRUSH | ENERGY
Query syntax: TRIGger:MODE?<PMT>
Return parameters: <CRD>, NONE | GONG | INRUSH | ENERGY
Header on: :TRIGGER:MODE<space><CRD><RMT>
Header off: <CRD><RMT>
Example: none
PROTection:CLEar
Type: All channels.
Description: This command clears the alarm message.
Setting syntax: PROTection:CLEar<PMT>
Setting parameters: none
Query syntax: none
Return parameters: none
Example: none
PROTection?
Type: All channels.
Description: This query returns the alarm message of all channels.
Bit position
15
14~6 5 4 3 2 1 0
Condition
FAN -
Energy
RCE
Inrush
RCE
Integrate
RCE
OCP OCR OVR
Bit weight
32768 - 32 16 8 4 2 1
