IV
Model identification
Model
1601 1/16 DIN Temperature Controller, Single Display
Code Output 1 - Heat or Cool
1 Relay, 3 Amps at 250 Vac (Resistive)
6 SSR Drive, 14 Vdc at 20 mA
Code Output 2 - Alarm
1 Relay, 1 Amp at 250 Vac (Resistive load)
Code
0 Add to complete model number
Code Instrument Power
3 100 - 240 Vac
5 24 Vac/dc
Code
0 Add to complete model number
1601 6 1 0 3 0 Typical Model Number
1601-0-0C.p65 5/2/00, 1:45 PM3
