Chromalox 1601 User Manual

A. 2
DEFAULT CONFIGURATION
PARAMETERS
The configuration parameters can be loaded with
predetermined default values. These data are the
typical values loaded in the instrument prior to
shipment from factory. To load the default values
proceed as follows:
a) The internal switch (V2, see fig. 9) should be
open.
b) The display will show:
c) Push the t pushbutton; the display will show
the firmware version.
d) Mantaining the pressure on the t pushbutton
push the s pushbutton also.
The instrument will show
e) Press s pushbutton to select between table 1
(european) or table 2 (american) default
parameter set. The display will show:
f) Press FUNC pushbutton; the display will show:
This means that the loading procedure has been
initiated. After about 3 seconds the loading
procedure is terminated and the instrument reverts
to the "CnF" parameter).
The following is a list of the default parameters
loaded during the above procedure:
PARAMETER TABLE 1 TABLE 2
P1 1 9
P2 0 °C0 °F
P3 400 °C 999 °F
P4 r r
P5 0 0
P6 H H
P7 r r
P8 OFF OFF
P9 0 0
P10 0 0
P11 0 0
P12 10 10
P13 2 2
P14 ON ON
P15 2 2
P16 30.0 30.0
P17 1.0 1.0
P18 -- --
P19 -- --
P20 00.3 00.3
P21 10 10
C n F
A. 0 1
d.F F
t b. 1
L. d t.
1601-A-0C.p65 5/2/00, 1:45 PM2
