CHRONTEL AN-B014

12 206-1000-014 Rev. 1.7 2020-07-14

3.0 REFERENCE DESIGN EXAMPLE

The following schematics are to be used as a CH7511B/7512B PCB design example only. It is not a complete design.

Those who are seriously doing an application design with the CH7511B/7512B and would like to have a complete

reference design schematic should contact Applications within Chrontel, Inc.

3.1 Schematics of Reference Design Example
