Front Side Marker Lamps
1. Remove the three fasteners from the inner wheel liner
and carefully peel back liner for access.
2. Firmly grasp the front side marker lamp socket and
rotate 1/4 turn counterclockwise to remove it from the
lamp assembly.
3. Remove bulb from the front side marker lamp socket
and replace with a new bulb.
4. Install front side marker lamp socket in lamp assembly
and rotate 1/4 turn clockwise to lock into place.
5. Position the inner wheel liner in place and install the
three fasteners.
Inner Wheel Liner Fasteners
Front Side Marker Lamp Bulb Removal
7
MAINTAINING YOUR VEHICLE 651
