The fuse access door is located on the end of the
instrument panel on the driver’s side behind the trim
panel cover. Use a coin or flat blade screwdriver to open
and close this access door.
Interior Fuses
Cavity Fuse Circuits
1 Not Assigned
2 15 Amp
Blue
Brake Lamp/Speed Control
3 7.5 Amp
Brown
Right High Beam, High Beam
Indicator Light
Cavity Fuse Circuits
4 15 Amp
Blue
Reverse/Turn signal Light
5 7.5 Amp
Brown
Left High Beam
6 15 Amp
Blue
Right Low Beam
7 7.5 Amp
Brown
Right Parking/Tail Light Side
Marker
8 15 Amp
Blue
Left Low Beam
9 15 Amp
Blue
Fog Light
10 7.5 Amp
Brown
Left Parking/Tail Light Side
Marker
11 7.5 Amp
Brown
License Plate/Instrument Cluster
Lighting/Symbol Lighting
12 7.5 Amp
Brown
Rear Fog Light (European Mar-
kets Only)
13 Not Used - Spare Fuse
14 Not Used - Spare Fuse
234 MAINTAINING YOUR VEHICLE
