Chrysler 2007 LX 300C User Manual

Cavity Car-
tridge
Fuse
Mini
Fuse
Description
1 — 20 Amp
Yellow
Left High Intensity Dis-
charge (HID) Headlight
- if equipped
2 — 20 Amp
Yellow
Right High Intensity
Discharge (HID) Head-
light - if equipped
3 — 15 Amp
Blue
Adjustable Pedals - if
equipped
4 — 20 Amp
Yellow
AC Clutch/Horn
5 — 20 Amp
Yellow
Headlight Washer - If
Equipped
6 — 15 Amp
Blue
Front Control Module
(FCM)
7 — 20 Amp
Yellow
Fog Lights - if equipped
8 — 15 Amp
Blue
Lights – License, Park,
Side Marker, Stop, Turn
9 — 15 Amp
Blue
Front Control Module
(FCM)
Cavity Car-
tridge
Fuse
Mini
Fuse
Description
10 — 5 Amp
Orange
Powertrain Control
Module (PCM)/Starter
11 — 25 Amp
Clear
Auto Shutdown/
Powertrain Control
Module (PCM)
12———
13———
14 — 25 Amp
Clear
Powertrain Control
Module (PCM)
15 — 20 Amp
Yellow
Injectors, Ignition Coils
16———
17 30 Amp
Pink
— Anti-lock Brakes System
(ABS) Valves - if
equipped/Powertrain
Control Module (PCM)
18 30 Amp
Pink
— Windshield Wiper/
Washer
364 MAINTAINING YOUR VEHICLE
