Chrysler 2007 LX 300C User Manual

Cavity Car-
tridge
Fuse
Mini
Fuse
Description
1 60 Amp
Yellow
— Ignition Off Draw (IOD)
2 40 Amp
Green
— Battery
3———
4 40 Amp
Green
— Battery
5 30 Amp
Pink
— Heated Seats - if
equipped
6 — 20 Amp
Yellow
Fuel Pump
7———
8 — 15 Amp
Blue
Ignition Switch/Airbag
Control Module (ACM)
9 — 20 Amp
Yellow
Console Power Outlet
10———
11 * ———
12 * ———
Cavity Car-
tridge
Fuse
Mini
Fuse
Description
13 * ———
14 — 10 Amp
Red
AC Heater Control/
Cluster/Sentry Key Re-
mote Keyless Entry
15 — 20 Amp
Yellow
Trailer Tow Brake Mod-
ule - if equipped
16———
17 — 20 Amp
Yellow
Cluster
18 — 20 Amp
Yellow
Selectable Power Outlet
19 — 10 Amp
Red
Stop Lights
20———
21———
22———
23———
24———
25———
MAINTAINING YOUR VEHICLE 367
7
