Cavity Cartridge Fuse Blade Fuse Description
F06 – – Not Used
F07 – – Not Used
F08 – 25 Amp Clear Engine Control Module (ECM)/Fuel Inj.
F09 – – Not Used
F10 – 20 Amp Yellow Power Transfer Unit (PTU) – If Equipped
F11 – – Not Used
F12 – 20 Amp Yellow Brake Vacuum Pump – If Equipped
F13 – 10 Amp Red Engine Control Module (ECM)/VSM (Engine
Stop/Start Only)
F14 – 10 Amp Red Drivetrain Control Module (DTCM)/Power
Transfer Unit (PTU) – If Equipped/RDM/Brake
System Module (BSM)/Brake Pedal Switch/EPB
(Electric Park Brake)
F15 – – Not Used
F16 – 20 Amp Yellow Ignition Coil
7
MAINTAINING YOUR VEHICLE 625
