Cavity Cartridge Fuse Blade Fuse Description
F17 – – Not Used
F18 – – Not Used
F19 40 Amp Green – Starter Solenoid
F20 – 10 Amp Red A/C Compressor Clutch
F21 – – Not Used
F22 – 5 Amp Tan Radiator Fan Enable
F23 – 70 Amp Tan Body Controller Module (BCM) – Feed 2
F23 – 50 Amp Red Voltage Stability Module (VSM) #2 – If Equipped
With Engine Stop/Start Option
F24 – – Not Used
F25B – 20 Amp Yellow Front Washer Pump – If Equipped with Engine
Stop/Start Option
F26 – – Not Used
F27 – – Not Used
F28 – 15 Amp Blue Transmission Control Module (TCM)
626 MAINTAINING YOUR VEHICLE
