Cavity Cartridge Fuse Blade Fuse Description
F55 – 10 Amp Red Blind Spot Sensors/Compass/Rearview Camera –
If Equipped
F56 – 15 Amp Blue Ignition Node Module (IGNM)/RF Hub
F57 – – Not Used
F58 – 10 Amp Red Occupant Classification Module/Voltage Stability
Module (VSM) #2 – If Equipped With Engine
Stop/Start Option
F59 30 Amp Pink – Drivetrain Control Module (DTCM)
F60 – 20 Amp Yellow Power Outlet – Center Console
F61 – – Not Used
F62 – – Not Used
F63 – 20 Amp Yellow Front Heated Seats – If Equipped
F64 – 20 Amp Yellow Heated Steering Wheel – If Equipped
7
MAINTAINING YOUR VEHICLE 629
