Cavity Cartridge Fuse Blade Fuse Description
F65 – 10 Amp Red
In Vehicle Temperature Sensor/Humidity Sensor/
Driver Assist System Module (DASM)/Park Assist
(PAM) – If Equipped With Engine Stop/Start Option
F66 – 15 Amp Blue Instrument Panel Cluster (IPC)/Electronic Climate
Control (ECC)
F67 – 10 Amp Red In Vehicle Temperature Sensor/Humidity Sensor/
Drivers Assist System Module (DASM)/Park
Assist (PAM) – If Equipped
F68 – – Not Used
F69 – 10 Amp Red Gear Shift Module (GSM)/Active Grill Shutter
(AGS). – If Equipped/EPB SW
F70 – 5 Amp Tan Intelligent Battery Sensor (IBS) – If Equipped with
Engine Stop/Start Option
F71 – 20 Amp Yellow HID Headlamp Right – If Equipped with Engine
Stop/Start Option
F72 – 10 Amp Red Heated Mirrors – If Equipped
630 MAINTAINING YOUR VEHICLE
