Cavity Cartridge
Fuse
Mini-
Fuse
Description
10 30 Amp
Pink
— Driver Door
11 30 Amp
Pink
— Passenger Door
12 — 20 Amp
Yellow
Cigar Lighters, Instru-
ment Panel & Power
Outlet Console Rear
15 40 Amp
Green
— HVAC Blower
16 — — Fuse — Spare
17 — — Fuse — Spare
18 — — Fuse — Spare
19 — — Fuse — Spare
20 — — Fuse — Spare
21 — — Fuse — Spare
22 — — Fuse — Spare
Cavity Cartridge
Fuse
Mini-
Fuse
Description
23 — 10 Amp
Red
Fuel Door/Diagnostic
Port
24 — 15 Amp
Blue
Radio Screen
25 — 10 Amp
Red
Tire Pressure Monitor
26 — — Fuse — Spare
27 — 25 Amp
Natural
Amplifier
31 — 25 Amp
Natural
Power Seats
32 — 15 Amp
Blue
HVAC Module/
Cluster
33 — 15 Amp
Blue
Ignition Switch/
Wireless Module
472 MAINTAINING YOUR VEHICLE
