Front Power Distribution Center Fuses
Cavity Fuse Circuits
1 20 Amp Yellow Left High Beam Headlight
2 20 Amp Yellow Right High Beam Head-
light
3— —
4 20 Amp Yellow Horn
5 25 Amp Clear Headlamp Washer
6 15 Amp Dk. Blue Front Control Module
(FCM)
7 20 Amp Yellow Fog Lamp
8 15 Amp Dk. Blue Park Lamp
9 15 Amp Dk. Blue Non ABS Brakes
10 5 Amp Orange Starter
11 20 Amp Yellow Auto Shutdown/
Powertrain Control Mod-
ule (PCM)
12 — —
13 — —
Cavity Fuse Circuits
14 25 Amp Clear Powertrain Control Mod-
ule
15 20 Amp Yellow Injectors, Ignition Coils
16 15 Amp Dk. Blue Powertrain Control Mod-
ule
17 30 Amp Pink Antilock Brake System
(ABS) Valves
18 30 Amp Pink Windshield Wiper/Washer
19 50 Amp Red Radiator Fan
20 20 Amp Lt. Blue Starter
21 50 Amp Red ABS Pump Motor
22 40 Amp Green Radiator Fan High/Low
23 50 Amp Red High Intensity Lighting
24 60 Amp Yellow Radiator Fan
25 30 Amp Pink Lighting Left High Beam/
Right Low Beam
26 — —
27 30 Amp Pink Lighting Left Low Beam/
Right High Beam
MAINTAINING YOUR VEHICLE 271
7
