Rear Power Distribution Center Fuses
Cavity Fuse Circuits
1 60 Amp Clear Ignition Off Draw
2 40 Amp Green Battery
3— —
4 40 Amp Green Battery
5 30 Amp Pink Heated Seat/Steering Col-
umn
6 20 Amp Yellow Fuel Pump
7— —
8 15 Amp Dk. Blue Ignition Start/Run - Start
9 20 Amp Yellow Console Power Outlet
10 10 Amp Red Rear Fog Lamp — If
Equipped
11 25 Amp C/BRKR Memory Module/Door
Locks
12 25 Amp C/BRKR Passenger Power Seat
13 30 Amp C/BRKR Door Module Run/Acc/
Delay
14 10 Amp Red Sentry Key/Remote Key-
less Entry/Cluster
Cavity Fuse Circuits
15 — —
16 — —
17 — —
18 20 Amp Yellow Selectable Power Outlet
19 10 Amp Red Stop Lamp
20 — —
21 — —
22 — —
23 — —
24 — —
25 — —
26 — —
27 10 Amp Red Airbag/Occupant Classifi-
cation Module
28 10 Amp Red Curtain Airbag - if
equipped
29 5 Amp Orange Sentry Key/Remote Key-
less Entry/Powertrain
Control Module Ignition
Feed
MAINTAINING YOUR VEHICLE 273
7
