Chrysler SRT8 2012 - Page 491

Cavity Car-
tridge
Fuse
Mini-
Fuse
Description
10 — 10 Amp
Red
Security
11 — 20 Amp
Yellow
Horns
12 — 10 Amp
Red
Air Conditioning Clutch
13 — — Fuse – Spare
14 — 25 Amp
Natural
Anti-Lock Brakes
15 — 25 Amp
Natural
Transmission
16 — — Fuse – Spare
18 50 Amp
Red
— Radiator Fan #2
Cavity Car-
tridge
Fuse
Mini-
Fuse
Description
19 50 Amp
Red
— Power Steering #2
20 30 Amp
Pink
— Wiper Motor
21 30 Amp
Pink
— Headlamp Washers
22 — — Fuse – Spare
23 — — Fuse – Spare
24 — — Fuse – Spare
28 — 25 Amp
Natural
Fuel Pump
29 — 15 Amp
Blue
Transmission/Shifter
30 — — Fuse – Spare
7
MAINTAINING YOUR VEHICLE 489
