Cavity Car-
tridge
Fuse
Mini-
Fuse
Description
31 — 25 Amp
Natural
Engine Module
32 — — Fuse – Spare
33 — — Fuse – Spare
34 — 25 Amp
Natural
Powertrain #1
35 — 20 Amp
Yellow
Powertrain #2
36 — 10 Amp
Red
Anti-Lock Brake Module
37 — 10 Amp
Red
Engine Controller/Rad
Fan Relays
38 — 10 Amp
Red
Airbag Module
Cavity Car-
tridge
Fuse
Mini-
Fuse
Description
39 — 10 Amp
Red
Power Steering
Module/AC Clutch
Relay
48 — 10 Amp
Red
AWD Module/Front
Axle Disconnect
49 — — Fuse – Spare
50 — — Fuse – Spare
51 — 20 Amp
Yellow
Vacuum Pump
52 — — Fuse – Spare
53 — — Fuse – Spare
490 MAINTAINING YOUR VEHICLE
