LS1 F 1 0 0 - T 2 0 0
Interrupted Stroke
PCI-100
RESET
ENTER
MENU
Industrial Electronic Controls
Inc
PROGRAMMABLE LIMIT SWITCH COMPONENTS
2 2
Programmable Limit Switch control in a 8x6x6 enclosure
Industrial resolver
Resolver cable with connector
The PCI-100LS Programmable Limit Switch receives position and motion feedback from the resolver. The resolver
is attatched to the main shaft of the press. The PLS knows when the press is engaged, how fast it is running, the
position of the crank shaft, and when the clutch is disengaged.
Many safety features are included such as:
•Motion detect
•Resolver decouple/slippage detect
•Resolver cable brake detect
•Key and Coded security
•Rugged Quality design
•Clutch monitor
•Zero motion cable break detect
