2.2 Fitting accessoriesl
WARNING - This appliance has been designed for
use with the brushes and tool specified by the
manufacturer. The use of other types may impair
its safety.
Always ensure machine is unplugged before fitting or
removing parts.
2.2.1 Fitting scarifying brushes
• Tip the machine brush head backwards towards the
handle, and push three scarifying brushes of the
same type onto the four drive pins on each of the
rotating heads (Fig.2).
• Fit retaining clip onto pins, ensuring it is located in
the groove on each pin.
• Return brush head to the floor.
• Remove brushes by simply removing retaining clip
and pulling brush off the drive pins.
• Always keep brushes in sets of three, to ensure
even wear and prevent vibration.
2.2.2 Fitting tools
• These tools (such as star-wheels carbide blocks
and scrapers) must to be bolted onto the machine.
• To bolt tool to machine two drive pins (diagonally
opposite each other) must be removed from each
of the rotating heads.
• Fit three matching tools over each pair of drive
pins
• Secure each tool using two M5 bolts. Always use
spring washers with bolts to minimise chance of
tools working itself loose.
IMPORTANT – regularly check that bolts are tight.
IMPORTANT – Never allow the brush head to rest
on the drive pins, always tip brush head back
when not in use.
2.3 Adjusting the handle height
From the upright position, lift the handle adjustment
lever and pull the handle backwards to a comfortable
working height, then press lever down to lock handle
in position.
3 Controls
The operating controls are located on the handle
(Fig.1).
1 - Start/stop lever
When raised switches motor ON and starts the
rotating heads, when released switches motor OFF
and stops the heads. Each time the lever is
operated the direction of head rotation is reversed,
improving the quality of cleaning and prolonging
disc/pad life.
2 - Handle adjustment lever
Used to adjust handle to a comfortable working
height.
4 Operation
4.1 Starting the machine
• Fully unwind the supply cord from the handle and
plug in to a convenient socket outlet.
• With the handle set at a comfortable working
height, and with both hands on the handle, lift the
start/stop lever to START the machine. Releasing
the lever will STOP the machine.
• WARNING - Never start the machine without
brushes or tools fitted.
• Normal movement of the machine is in a forward
and backward direction.
• Always work away from the supply socket to avoid
running into the supply cord.
4.2 Using the machine
• Fit brushes or tools suitable for the surface to be
cleaned / prepared.
• Adjust handle to suit operator
• Tilt the machine slightly backwards so that the
brushes / tools are clear of the floor and wheel the
machie to the area to be cleaned.
• Switch on the machine. Always work away from the
mains socket – this will help to avoid running into
the cable.
• Scarifying is normallya dry process. Because of the
extremely harsh abrasive action of scarifying
brushes and tools, only resiliant floors such as
concrete, metal tile etc. should be scarified
• Walk slowly behind the machine, overlapping each
pass to ensure an even finish.
• Do not keep the machine rotating on one spot as
this could damage the floor surface.
• Should the machine start to vibrate, or resist the
cleaning action on the floor, check the brushes /
tools for wear.
• Each area of the floor should be covered at half
walking pace. Some floors may require extra
passes to process it thoroughly.
• On reaching the original starting point, position the
machine to process another path parallel to the first
and overlapping by 50mm.
• When the entire floor area has been covered, clear
debris using suitable vacuum cleaner or sweeper.
4.3 Adding weights
• Before adding additional weights switch off the
machine.
• Unscrew knob and lift off clamping bar.
• Add additional weight as required, and refit
clamping bar.
4.4 When work is finished
• When work is finished, unplug the machine from
the power supply, remove weights, raise the brush
head and remove the drivebacks, and abrasive
discs or pads. Wipe over the machine with a damp
cloth.
• Remove and clean brushes or tools.
