8 Technical specification
Machine is of Class I construction. Enclosure to IP2X.
Models - 230 V ~ 50 Hz. fitted with 15m supply cord type H05VV-F 3x1.0mm² (10A), and plug.
Model R48HR R76HD
Motor rating W 1500 1500
Head speed rpm 400 300
Brush / tool diameter cm 20 30
Working width cm 48 76
Weight (machine only) (see note 3) kg 60 68
Length cm 75
Width cm 48 76
Height (handle upright) cm 112 112
Sound pressure level (see note 1) dB(A) 65 65
Handle vibration (see note 2) m/s² < 2.5 < 2.5
1 - Sound pressure levels measured at a distance of 1 metre from machine and 1,6 metres above
the floor, when used on a hard floor. Measurements recorded using a hand held meter.
2 - Handle vibration does not exceed 2,5 m/s², when operating on any surface.
Measurements recorded by an independent test laboratory.
3 - All machines supplied with two 17kg weights.
9 Accessories
Items Application
Part No.
For use with
R48HD
Part No.
For use with
R76HD
Horseshoe weight Spare weights 17kg each 03-7004-0000 03-7004-0000
Retaining clips Hold brushes nto HD machiens 03-6938-0000
Crimped wire brush Chequer plate cleaning 11-2041-0500 11-3041-0500
Concrete finishing brush Steel wire 18G 11-2043-0500 11-3043-0500
Spark free scarifying brush Bronze wire 18G 11-2045-0000
General scarifying brush Steel wire 3x16G 11-2049-0500 11-3049-0500
HD scarifying brush Steel wire 2x14G 11-2051-0500 11-3051-0500
Rubber removal Starwheels 05-4084-0000 02-3980-0000
Concrete removal Widea wheels 05-4083-0000
Concrete preparation Fine carbide block 05-4078-0000
Paint removal Medium carbide block 05-4079-0000
Coatings removal Coarse carbide block 05-4080-0000
Foam removal Twisted wire 05-3886-0000 05-3893-0000
Flat tip scraper Ice breaking 05-4082-0000
IMPORTANT : Genuine accessories are only available from authorised Service Agents or Truvox Customer
Service Dept.
