MAN1010119 rel. 01 dated 30.01.2014 page no. 11 of 52 page
www.rheavendors.com tel: 0039 02 966 551 fax: 0039 02 96 55 086 e mail: rheavendors@rheavendors.com
rheavendors group's sole property
cino eC PRO by
03.20. product canisters
03.21. miscellaneous
03.22. notes
max. two instant, according to the machine configuration; single
(55 mm) or double (110 mm) width; dispensing worm screws 9
mm or 18 mm in pitch; with mixer gear and product shaker, if
arranged by the configuration and with standard or reduced
product slide outlet (see 05.23.);
-
instant canister capacity:
- coffee beans canister (or hopper) capacity: 0.8 kg
machine parameters programmable by means of a flash key or
selection keyboard; NRI G13 or similar payment system
compartment; protocols: serial, parallel, executive, MDB; data
collection by means of a flash key (see 09.06.);
the water and energy supply tolerance limits that can ensure a
good and proper operation of the cino eC PRO machine are:
water:
- total hardness:
- recommended conductivity:
(*) if harder, please use anti-limestone filters;
energy:
- nominal voltage:
room (during storage and operation):
- temperature:
- relative humidity:
electric consumption:
- power (vending phase):
the power supply cable supplied with the vending machine
shall not be altered under any circumstance; in case of loss
or damage replace it by using an original component only;
make sure that the electric installation can deliver the power
suitable for the machine (see 03.03.);
a good ground connection is not only a legal obligation for the
protection of users and operators, but it can also provide
for
correct power supply;
from 10 °f to 25 °f (*)
400 μS @ 20 °C
+10 % /- 15 %
5 °C ÷ 35 °C
max 80 %
340 Wh
