CipherLab 9700A User Manual

141
Customize Project Configuration
Item
Description
Enable SSH
Select the checkbox to enable SSH.
Generate SSH Log
Select the checkbox to generate SSH log.
Authentication Type
Click the drop-down menu to select between Key File and
Name/Pwd.
 Load a profile key:
Transfer a key file (*.pem or *.ppk) to your mobile computer.
Click Advance button to bring up the dialog. Click the
“Import ” to import the key file.
 Name/Password:
Or with Name/Pwd selected, you can access the remote server
using Name and Password.
Click the Advance button and then key in your Login
name and Password respectively.
The other settings on “
SSH Key File” window is depicted as follows:

CipherLab 9700A Specifications

General

Brand	CipherLab
Model	9700A
Category	PDA
Language	English
