CHAPTER 3
Installing the Chassis
• Rack Mount the Chassis, on page 15
• Installing a Cable Management Bracket, on page 30
• Install the Air Filter , on page 31
• Ground the Chassis, on page 34
• Power Supply Unit Input and Output Ranges, on page 38
• Connect AC Power to the Chassis, on page 41
• Connect DC Power to the Chassis, on page 52
Rack Mount the Chassis
The chassis can be mounted on a 4-post rack.
Statement 1032—Lifting the Chassis
To prevent personal injury or damage to the chassis, never attempt to lift or tilt the chassis using the
handles on modules, such as power supplies, fans, or cards. These types of handles are not designed to
support the weight of the unit.
Warning
Statement 1006—Chassis Warning for Rack-Mounting and Servicing
To prevent bodily injury when mounting or servicing this unit in a rack, you must take special precautions
to ensure that the system remains stable. The following guidelines are provided to ensure your safety:
• This unit should be mounted at the bottom of the rack if it is the only unit in the rack.
• When mounting this unit in a partially filled rack, load the rack from the bottom to the top with the
heaviest component at the bottom of the rack.
• If the rack is provided with stabilizing devices, install the stabilizers before mounting or servicing
the unit in the rack.
Warning
Hardware Installation Guide for Cisco 8200 Series Routers
15
