Reprogramming the Control Module
When installing a new cell of the same size – or – clearing the flashing Check Cell LED:
This procedure will reset the system’s internal count of production hours. This should be done in order
to clear the Check Cell light when flashing and any time a new cell (of the same size) is installed.
1. Press the On/Off switch to deactivate the Control Module. (Leaving power on at power source)
2. Hold down the chlorine Adjust button until the LED’s on the chlorine output power graph light
up. Take note of how many LED’s are displayed: 1 LED (EDGE15), 4 LEDs (EDGE25), or 8 LEDs
(EDGE40).
3. Tap the Adjust button once, then let the Control Module sit until the lights turn off.
4. Hold down the Adjust button until the LED’s light back up on the chlorine output power graph.
5. Tap the Adjust button twice (confirm that the same number of LED’s are lit up as on Step #2
above), let the Control Module sit until the lights turn off, then hit On/Off button to turn unit
back ON.
6. Turn off power at the power source (breaker, timer, etc…) for about 30 seconds.
7. Turn power back on at the power source.
8. Allow the salt system and pump to run for at least 5 minutes to calibrate before shutting it off
again.
When installing a new cell of a different size:
If a different size cell is to be used (ex: upgrading to a new Cell of a larger size), the Control Module needs
to be set in order to work correctly with the new Cell size. Follow these instructions to change the Control
Module to the correct Cell Type.
1. Press the On/Off switch to deactivate the Control Module. (Leaving power on at power source)
2. Hold down the chlorine Adjust button until the LED’s on the chlorine output power graph light
up.
3. Press the chlorine Adjust button to set the Control Module to a EDGE15 (1 LED light displayed),
EDGE25 (4 LED lights displayed), or EDGE40 (8 LED lights displayed).
4. Once desired size is chosen, let the Control Module sit until the lights turn off, then hit On/Off
button to turn unit back ON.
5. Turn off power at the power source (breaker, timer, etc…) for about 30 seconds.
6. Turn power back on at the power source.
7. Allow the salt system and pump to run for at least 5 minutes to calibrate before shutting it off
again.
