Circutor URBAN Series - Dimensions and Overview

Dimmensions
and Overview
1
2
6
3
4
5
(2)
Sockets may vary depending on the model.
1
2
8
3
4
5
7
1
2
3
4
5
URBAN MASTER
URBAN SLAVEURBAN M21 - T21 - M22
- T22 - T22-C - T24-MIX
1.- Hat 4.- Key lock access 7.- Touch screen
2.- LED Beacons 5.- Base 8.- RDIF Reader
3.- Socket
(2)
6.- Display & RDIF Reader
13Installation Guide
URBAN
