(3)
This is the minimum cable section recommended for the maximum AC input current, the final section must
be calculated by a qualified technician taking into account the specific conditions of installation.
(4)
Optional.
(5)
The T24-MIX model has 2 double sockets. Each double socket consists of 2 sockets with dierent connec-
tors and can not be connected simultaneously.
MECHANICAL DATA
Enclosure rating
IP54 / IK10
Enclosure material
Aluminium & ABS
Enclosure door
Frontal key locked door
Net weight
55Kg
Dimensions (W x H x D)
450 x 1550 x 290 mm
STANDARDS
IEC 61851-1: 2010, IEC 61851-22: 2001, IEC 62196-1: 2014, IEC 62196-2: 2011, 2014/35/UE, LVD;2014/30/
UE, ISO 14443A/B
22
URBAN
Installation Guide
