Performance
Verification
Required to Perform the Test:
Import/Configure the Test Files
Before performing the calibration procedure, you must import the test files to the station(s) or
network where the performance verification procedure is being performed. The following steps
will create a category called Calibration. Import the test files into the Calibration category, and
configure the test files to run.
To ensure you have the correct test files, re-import the files any time you update easy-wire or
anytime you haven’t run the test in a while. Re-importing test files guarantees they are the
correct version.
1. Start the easy-wire software.
2. From the Main Menu, click Utilities.
A multimeter capable of
measuring AC and DC
voltages. For both AC
and DC the meter needs
an input resistance of
10Mohm (+/-10%) and a
measurement accuracy
better than +/-1%.
(avoid using a bench top
meter)
Standard Pin Probe
Test Leads for a
multimeter.
