LEGEND
1. Navigation & Avionics Configuration Buttons
2. Percent Power
3. Bus Voltages
4. Airspeed Window
5. Airspeed Tape
6. Autopilot Annunciations
7. Aircraft Reference Symbol
8. Bank Angle Indicator
9. Skid/Slip Indicator
10. Pitch Ladder
11. Flight Director Steering Command Bars
12. Vertical Deviation Indicator (VDI)
13. Altitude Tape
14. Altitude Window
15. Vertical Speed Indicator (VSI)
16. Brightness Control (BRT/DIM)
17. Mode and Display Selection
18. Wind Vector
19. Engine Information Data Block
20. Horizontal Situation Indicator (HSI)
21. Horizontal Deviation Indicator (HDI)
22. Air Data Block
SR22_FM07_2221A
16
1817 22 21
12 1513 141110
987654
1
Tach 2400 RPM
MAP
32.0
in-Hg
FF
16.0
GPH
Oil
49
PSI
32
1
171920
To Next Page
