Cirrus Design Section 9
SR22 Supplements
Section 2 - Limitations
Use of auxiliary AUDIO IN entertainment input and the optionally
installed XM Radio System is prohibited during takeoff and landing.
Section 3 - Emergency Procedures
In the event of an audio panel power failure, the audio system will
revert to COM 1 for the pilot’s mic and headphones and the pilot will
have transmit and receive capability.
Section 4 - Normal Procedures
Refer to Section 7 - System Description in this supplement for a
complete description and operation of the Audio Control Panel.
Section 5 - Performance
No change from basic Handbook.
Section 6 - Weight & Balance
Garmin GMA 340 Audio System: No change from basic Handbook.
Installation of the optional XM Radio System adds the following
optional (Sym = O) equipment at the weight and arm shown in the
following table.
Section 7 - System Description
Power On and Fail-safe Operation
The Audio Control Panel is powered ‘OFF’ when the left inner knob
(PILOT) is at the full CCW (counter-clockwise) position. Rotating the
knob CW (clockwise) activates the unit. CW rotation of knob beyond
the ‘on’ detent increases pilot ICS (intercom system) volume.
ATA /
Item
Description Sym Qty Part Number
Unit
Wt
Arm
22-01 XM Receiver O 1 16665-001 1.7 114.0
Revision 02: 07-18-05
