Cirrus SR22T Maintenance Manual

24-30
Page 14
All
EFFECTIVITY:
CIRRUS AIRPLANE MAINTENANCE MANUAL MODELS SR22 AND SR22T
15 Dec 2014
2. MAINTENANCE PRACTICES
A. Alternator 1 (See Figure 24-302)
(1) Removal - Alternator 1
(a) Set BAT 1, BAT 2, and AVIONICS switches to OFF positions.
(b) Remove engine cowling. (Refer to 71-10)
(c) Disconnect battery 1. (Refer to 24-30)
(d) Disconnect cables and wires from alternator terminals.
(e) Remove nuts and washers securing alternator to engine. Remove alternator from airplane.
(f) Discard old gasket and remove residual gasket material from alternator and engine.
(2) Installation - Alternator 1
(a) Position alternator and new gasket to engine. Hand tighten washers and nuts in an alter-
nating pattern securing alternator to engine.
(b) Torque nuts to 180 - 220 in-lb (20.3 - 24.8 Nm) in an alternating pattern.
CAUTION: Cable shielding could be installed to the Power and/or Field wire harness. If
installed, attach cable shielding wire(s) to ground terminal on alternator. Do
not install cable shielding wire(s) to AUX power terminal.
(c) Connect cables and wires to alternator terminals.
(d) Connect battery 1. (Refer to 24-30)
(e) Install engine cowling. (Refer to 71-10)

Cirrus SR22T Specifications

General

Manufacturer	Cirrus Aircraft
Engine	Continental TSIO-550-K
Horsepower	315 hp
Max Takeoff Weight	3, 600 lbs
Service Ceiling	25, 000 ft
Cabin Width	49 in
Cabin Height	50 in
Seating Capacity	4
Avionics	Cirrus Perspective+ by Garmin
Category	Single-engine piston aircraft
Propeller	Hartzell 3-blade composite
Wingspan	38 ft 4 in
Length	26 ft
Height	8 ft 11 in
Maximum Cruise Speed	213 KTAS
Fuel Capacity	92 gallons
Stall Speed	64 knots
Safety Features	Cirrus Airframe Parachute System (CAPS)
Cruise Speed	183 knots
