Cirrus SR22T Maintenance Manual

CIRRUS AIRPLANE MAINTENANCE MANUAL MODELS SR22 AND SR22T
24-30
Page 19
Serials 22-1602, 22-1821, 22-1840, 22-1863 & subs w/
o Perspective Avionics
EFFECTIVITY:
Figure 24-303
Alternator 2 - Serials 22-1602, 22-1821, 22-1840, 22-1863 & subs w/o Perspective Avionics
13
2
12
Serials 22-1602, 22-1821, 22-1840, 22-1863 & subs.
Serials 22-0002 thru 22-1601, 22-1603 thru 22-1820,
22-1822 thru 22-1839, 22-1841 thru 22-1862.
10
11
13
2
2
2
14
13
1
3
12
2
3
15
4
1
3
2
2
3
LEGEND
1. Alternator
2. Washer
3. Nut
4. Gasket
5. Mounting Flange
6. Casting Web
7. Alternator Housing
8. Output Terminal
9. Rear Housing Cooling Slots
10. Shear Coupling Assembly
11. Bracket
12. Bolt
13. Clamp
14. Spacer
15. Blast Tube
16. Cable
17. Wire Harness
10
4
SR22_MM24_1432D
9
6
7
5
8
16
17
16
17
31 May 2011

Cirrus SR22T Specifications

General

Manufacturer	Cirrus Aircraft
Engine	Continental TSIO-550-K
Horsepower	315 hp
Max Takeoff Weight	3, 600 lbs
Service Ceiling	25, 000 ft
Cabin Width	49 in
Cabin Height	50 in
Seating Capacity	4
Avionics	Cirrus Perspective+ by Garmin
Category	Single-engine piston aircraft
Propeller	Hartzell 3-blade composite
Wingspan	38 ft 4 in
Length	26 ft
Height	8 ft 11 in
Maximum Cruise Speed	213 KTAS
Fuel Capacity	92 gallons
Stall Speed	64 knots
Safety Features	Cirrus Airframe Parachute System (CAPS)
Cruise Speed	183 knots
