Cirrus SR22T Maintenance Manual

24-30
Page 60
Serials w/ Perspective Avionics
EFFECTIVITY:
CIRRUS AIRPLANE MAINTENANCE MANUAL MODELS SR22 AND SR22T
01 Jan 2012
AA.Volt / Amp Meter - Serials w/ Perspective Avionics (See Figure 24-308)
Note: Voltage and amperage are displayed on the screens of the MFD and PFD.
(1) Operational Test - Volt / Amp Meter
(a) Set BAT1 and AVIONICS switches to ON positions.
(b) Verify BAT 1 current indicates between 0 and 10 amps.
(c) Verify Essential Bus voltage indicates 26 ±2 VDC.
(d) Verify Main Bus 1 voltage indicates 26 ±2 VDC.
(e) Verify Main Bus 2 voltage indicates 26 ±2 VDC.
(f) Verify ALT1 indicates zero amps.
(g) Verify ALT2 indicates zero amps.
(h) Turn on large electrical loads (landing light, nav lights, pitot heat, etc.) to ensure more
amps are drawn when larger electrical loads are introduced.
(i) Verify ammeter indicates an increase in amperage.
(j) Set BAT1 and AVIONICS switches to OFF positions.

Cirrus SR22T Specifications

General

Manufacturer	Cirrus Aircraft
Engine	Continental TSIO-550-K
Horsepower	315 hp
Max Takeoff Weight	3, 600 lbs
Service Ceiling	25, 000 ft
Cabin Width	49 in
Cabin Height	50 in
Seating Capacity	4
Avionics	Cirrus Perspective+ by Garmin
Category	Single-engine piston aircraft
Propeller	Hartzell 3-blade composite
Wingspan	38 ft 4 in
Length	26 ft
Height	8 ft 11 in
Maximum Cruise Speed	213 KTAS
Fuel Capacity	92 gallons
Stall Speed	64 knots
Safety Features	Cirrus Airframe Parachute System (CAPS)
Cruise Speed	183 knots
