Cirrus SR22T Airplane Maintenance Manual

22-11
Page 20
Serials 22-0435 - 1306 after SB 2X-22-03, 1307 & subs
w/ Avidyne Avionics
EFFECTIVITY:
CIRRUS AIRPLANE MAINTENANCE MANUAL MODELS SR22 AND SR22T
15 Jun 2010
Figure 22-116
Flight Director - Serials 22-0435 - 1306 after SB 2X-22-03, 1307 & subs w/ Avidyne Avionics (Sheet 1 of 2)
SR22_MM22_2066A
LEGEND
1. Pushbutton
2. Switch
3. Seal
4. Spacer
5. Mounting Sleeve
6. Connector
7. Screw
8. Relay
9. Washer
10. Nut
NOTE
To release/engage cams, rotate locking
screws clockwise/counter-clockwise.
2
57
41
8
10
6
3
12
11
9
NC
NO
C
INSTRUMENT PANEL
(REF)
7
6
5
4
4
3
3
2
1
8
9
10
TO RADIO MODULE
(REF)
WIRING HARNESS
(REF)
To facilitate switch installation, discard one
seal and spacer if required.
Serials 22-0435 thru 22-1306 after SB 2X-22-03,
Serials 22-1307 & subs w/ Avidyne Avionics.
