Cirrus SR22T Airplane Maintenance Manual

CIRRUS AIRPLANE MAINTENANCE MANUAL MODELS SR22 AND SR22T
22-11
Page 7
Serials w/ PFD & Perspective Avionics
EFFECTIVITY:
Figure 22-111
System 55X Schematic - Serials w/ PFD & Perspective Avionics (Sheet 3 of 3)
SR22_MM22_3018
A/P DISC
SWITCH
L
R
S
T
H
D
T
R
K
A
L
T
R
D
Y
D
N
T
R
I
M
U
P
2
M
I
N
T
U
R
N
C
O
O
R
D
I
N
A
T
O
R
H
I
L
O
N
O
I
T A
M
R
O
F
N
I
H
C
T
I
P
O
N
MFD PFD INTEGRATED
AVIONICS UNIT 2
FLIGHT DIRECTOR
SWITCHES
(OPTIONAL)
A
P
O
N
A
P
O
F
F
F
D
O
N
TURN COORDINATOR
ROLL TRIM CARTRIDGE
PITCH TRIM
CARTRIDGE
PITCH TRIM
SERVO
ALTITUDE TRANSDUCER
SYSTEM 55X/55SR
AUTOPILOT
15 Jun 2010

Cirrus SR22T Specifications

General

Manufacturer	Cirrus Aircraft
Engine	Continental TSIO-550-K
Horsepower	315 hp
Max Takeoff Weight	3, 600 lbs
Service Ceiling	25, 000 ft
Cabin Width	49 in
Cabin Height	50 in
Seating Capacity	4
Avionics	Cirrus Perspective+ by Garmin
Category	Single-engine piston aircraft
Propeller	Hartzell 3-blade composite
Wingspan	38 ft 4 in
Length	26 ft
Height	8 ft 11 in
Maximum Cruise Speed	213 KTAS
Fuel Capacity	92 gallons
Stall Speed	64 knots
Safety Features	Cirrus Airframe Parachute System (CAPS)
Cruise Speed	183 knots
