Cirrus SR22T Airplane Maintenance Manual

22-11
Page 6
Serials w/ PFD and Avidyne Avionics
EFFECTIVITY:
CIRRUS AIRPLANE MAINTENANCE MANUAL MODELS SR22 AND SR22T
15 Jun 2010
Figure 22-111
System 55X Schematic - Serials w/ PFD and Avidyne Avionics (Sheet 2 of 3)
T
U
R
N
C
O
O
R
D
I
N
A
T
O
R
2
M
I
N
L
R
TURN COORDINATOR
SYSTEM 55X AUTOPILOT
ROLL TRIM CARTRIDGE
SR22_MM22_2145
PITCH TRIM CARTRIDGE
FLIGHT DIRECTOR
SWITCHES
PITCH TRIM SERVO
GNS 430 TRANSCEIVER #2
GNS 430 TRANSCEIVER #1
PFD FAIL
RELAY
ALTITUDE TRANSDUCER
PFD

Cirrus SR22T Specifications

General

Manufacturer	Cirrus Aircraft
Engine	Continental TSIO-550-K
Horsepower	315 hp
Max Takeoff Weight	3, 600 lbs
Service Ceiling	25, 000 ft
Cabin Width	49 in
Cabin Height	50 in
Seating Capacity	4
Avionics	Cirrus Perspective+ by Garmin
Category	Single-engine piston aircraft
Propeller	Hartzell 3-blade composite
Wingspan	38 ft 4 in
Length	26 ft
Height	8 ft 11 in
Maximum Cruise Speed	213 KTAS
Fuel Capacity	92 gallons
Stall Speed	64 knots
Safety Features	Cirrus Airframe Parachute System (CAPS)
Cruise Speed	183 knots
