Rev Z Page 55 11/28/2011
Copyright © 2011 by Cirus Controls, LLC. All Rights Reserved. No part of this material may be reproduced without the express
written permission of Cirus Controls LLC for each reproduction.
Appendix A: System Drawings
Appendix B: Spare parts list
0301925 SpreadSmart Rx TFT Display assembly in housing
IDM7TFT SS Rx TFT for International Dash mount
TS-3001 5v power cable for Drive by Download bridge (truck mount)
030193 SpreadSmart Rx Mini CPU in Red Housing (Xtec box)
022054 SpreadSmart Rx Mini Touch screen (stand alone - no housing)
0205086 Touch screen cable (10 foot length) M12 to M12
000453 Replacement 3 volt battery
MK-1003 Main Power Cable
TS-2004 Speedo and Remote Blast/Pass Cable
TS-2004E Speedo Enclosure Series Cable (12ft)
Appendix D – Typical Frequency Settings by Valve Mfg
Brand Valve (prewet systems) 100 Hz
Husco – Section Valves – 100 Hz
HydraForce (Cirus manifold)- 220 Hz
Parker - 60 Hz
Rexroth (MP18) 180 Hz
Sauer Dan Foss - PVG32 80 Hz
