Cisco 1000 Series Hardware Installation Guide

DATA LED10CD LED9
Figure 24: Cisco 1121-4Px LED Indicators
PoE LED2VPN1
Ethernet switch ports 0-34Status3
GE 0/0/1 LED6GE 0/0/0 RJ45 LED5
Micro USB console LED8GE 0/0/0 RJ45 LED7
USB LED9
Figure 25: Cisco 1121-4PLTEP LED Indicators
PoE LED2VPN1
Ethernet switch ports 0-34Status3
GE 0/0/1 LED6GE 0/0/0 RJ45 LED5
Micro USB console LED8GE 0/0/0 RJ45 LED7
USB LED9
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
14
Overview of Cisco 1000 Series Integrated Services Routers
LED Indicators

Cisco 1000 Series Specifications
