Ground Lug2

Figure 49: Chassis Ground Connection-Cisco 1121X-8PLTEP

Screw (UNC 6-32)1

Ground Lug2

Connect Power Cable

Power supply of the Cisco 1000 Series Intergrated Services Routers is an external AC to DC power adapter.

The external DC power connector plugs into the router's 4 points power connector.

Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router

Install and Connect the Router

Connect Power Cable
