Cisco 1000 Series Hardware Installation Guide

Control SourceDescriptionLED ColorPort
I/O sideOff: No USB device
discovered.
Green
USB
On: USB device
discovered.
Table 4: LED Indicators for C1101 and C1109
Control SourceDescriptionColorLED
I/OSystem power status
Off: No power
Greensteady on: Normal
operation
Green blink: Boot up
phase or in ROM monitor
mode
Amber steady on or
blink: Some issues with
the system.
Green+AmberPower
I/OVPN Status
Off: No tunnel
Steady on:At least one
tunnel is up
GreenVPN OK
I/OLink activity
Off: No link
Steady on: Link
Blink: TXD/RXD Data
GreenEthernet switch GE LAN
ports
I/OLink activity
Off: No link
Steady on: Link
Blink: TXD/RXD Data
GreenGE WAN ports
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
19
Overview of Cisco 1000 Series Integrated Services Routers
LED Indicators
