Cisco 1700 Router Overview 1-7
Front-Panel LEDs
WICØ
ACT/CHØ Green Serial and DSU/CSU cards—Blinks when data is being sent to or received from
the port on the card in the WICØ slot.
ISDN cards—On solid when the first ISDN B channel is up for the card in the
WICØ slot.
2-port serial cards—Blinks when there is data being sent to or received from the
first port on the 2-port card in the WICØ slot.
ACT/CH1 Green Serial and CSU/DSU cards—Remains off.
ISDN cards—On solid when the second ISDN B channel is up for the card in the
WICØ slot
2-port serial cards—Blinks when there is data being sent to or received from the
second port on the 2-port card in the WICØ slot.
WIC1
ACT/CHØ Green Serial and DSU/CSU cards—Blinks when data is being sent to or received from
the port on the card in the WIC1 slot.
ISDN cards—On solid when the first ISDN B channel is up for the card in the
WIC1 slot.
2-port serial cards—Blinks when there is data being sent to or received from the
first port on the 2-port card in the WIC1 slot.
ACT/CH1 Green Serial and DSU/CSU cards—Remains off.
ISDN cards—On solid when the second ISDN B channel is up for the card in the
WIC1 slot.
2-port serial cards—Blinks when there is data being sent to or received from the
second port on the 2-port card in the WIC1 slot.
Table 1-4 Front-Panel LEDs (Continued)
LED Label Color Description

Cisco 1700 Specifications

General

Form Factor	Desktop
WAN Slots	1
VPN Support	Yes
Connectivity Technology	Wired
Flash Memory (max)	16 MB
Flash Memory	8 MB
Routing Protocols	BGP, EIGRP, OSPF
Product Type	Router
Data Link Protocol	Ethernet, Fast Ethernet
Remote Management Protocol	SNMP, Telnet
Features	Firewall, VPN, NAT, DHCP
Supported Protocols	BGP, EIGRP, OSPF
Security Features	Firewall
Humidity	10%
