Extending Cisco End-to-End Solutions
As part of thecomprehensive Cisco end-to-end networking solution, the Cisco 1700Series routers enable businesses
to extend a cost-effective, seamless network infrastructure to the small branch office. The Cisco 1700 Family of
access routers includes the Cisco 1751 Router and Cisco 1721 Router—a modular device optimized for data-only
connections. WAN cards work with both devices, as well as with Cisco 1600, 2600, and 3600 Series routers. They
are powered by Cisco IOS Software for robust WAN service between branches and central offices in organizations
with multiple sites. Both feature RISC-based processors to provide performance for encryption and support for
emerging broadband technologies.
The Cisco 1751 Router also shares VoIP technology and analog voice interface cards with Cisco 2600 and 3600
Series routers. This feature provides an end-to-end solution for multiservices communications between offices,
simplifying inventory needs and leveraging IT expertise across more devices in an organization.
For a complete list of physical interfaces, see Tables 3, 4, 5, and 6.
Table 3 Physical Interfaces/Architecture
One 10/100 BaseT Fast Ethernet Port
(RJ45)
Automatic speed detection; automatic duplex negotiation; VLAN support
One Voice Interface Card Slot Supports a single voice interface card with two ports per card
Two WAN Interface Card/Voice
Interface Card Slots
Supports any combination of up to two WAN interface cards or voice
interface cards
Ethernet WAN Interface Cards Supports PPP and PPPoE; operates in full and half-duplex modes
One Auxiliary (AUX) Port RJ-45 jack with RS232 interface (plug compatible with Cisco 2500 Series
AUX port); asynchronous serial DTE with full modem controls (CD, DSR,
RTS, CTS); asynchronous serial data rates up to 115.2 kbps
One Console Port RJ-45 jack with RS232 interface (plug compatible with Cisco 1000/1600/
2500 series console ports); asynchronous serial DTE; transmit/receive
rates up to 115.2 kbps (default 9600 bps, not a network data port); no
hardware handshaking such as RTS/CTS
One Internal Expansion Slot Supports hardware-assisted services such as encryption (up to T1/E1)
RISC Processor Motorola MPC860P PowerQUICC at 48MHz
Table 4 WAN Support
Asynchronous Serial Interfaces on
Serial WAN Interface Cards
Interface speed: up to 115.2 Kbps; asynchronous serial protocols:
Point-to-Point Protocol (PPP), Serial Line Internet Protocol (SLIP);
asynchronous interface; EIA/TIA-232
ISDN WAN Interface Cards ISDN dialup and ISDN leased line (IDSL) at 64 and 128 Kbps;
encapsulation over ISDN leased line; Frame Relay and PPP
ADSL WAN Interface Cards Supports ATP adaption Layer 5 (AAL5) services and applications;
interoperates with Alcatel DSLAM with Alcatel chipset and Cisco 6130/
6260 DSLAM with Globespan chipset; ANSI T1.413 issue 2 and ITU 992.1
(G.DMT) compliant
