Cisco 1841 - Page 5

5
Cisco 1841 Integrated Services Router with AIM-VPN/BPII-Plus and Cisco 2801 Integrated Services Router with AIM-VPN/EPII-Plus
OL-8719-01
Cisco 1841 and Cisco 2801 Routers
The physical interfaces are separated into the logical interfaces from FIPS 140-2 as described in the
Table 4:
There are two USB ports but they are not supported currently. The ports will be supported in the future
for smartcard or token reader.
Table 3 Cisco 1841 Ethernet Indicators
Name State Description
Duplex Solid Green
Off
Full-Duplex
Half-Duplex
Speed Solid Green
Off
100 Mbps
10 Mbps
Link Solid Green
Off
Ethernet link is established
No link established
Table 4 Cisco 1841 FIPS 140-2 Logical Interfaces
Router Physical Interface FIPS 140-2 Logical Interface
10/100 Ethernet LAN Ports
HWIC/WIC/VIC Ports
Console Port
Auxiliary Port
Data Input Interface
10/100 Ethernet LAN Ports
HWIC/WIC/VIC Ports
Console Port
Auxiliary Port
Data Output Interface
10/100 Ethernet LAN Ports
HWIC/WIC/VIC Ports
Power Switch
Console Port
Auxiliary Port
Control Input Interface
10/100 Ethernet LAN Port LEDs
AIM LED
System OK LED
System Activity LED
Compact Flash LED
Console Port
Auxiliary Port
Status Output Interface
Power Plug Power Interface
