Cisco 1841 Integrated Services Router with AIM-VPN/BPII-Plus and Cisco 2801 Integrated Services Router with AIM-VPN/EPII-Plus
OL-8719-01
Cisco 1841 and Cisco 2801 Routers
The Cisco 2801 router features a console port, an auxiliary port, Universal Serial Bus (USB) port, two
high-speed WAN interface card (HWIC) slots, Voice interface card (VIC) slot, WIC/VIC slot, two10/100
Fast Ethernet RJ45 ports, and a Compact Flash (CF) drive. The Cisco 2801 router has two slots for
AIM-VPN/EPII-Plus cards
1
, two internal packet voice data modules (PVDMs), and two fast Ethernet
connections. Figure 4 and Figure 5 show the front and read panels of the router. The front panel consists
of 14 LEDs: two duplex LEDs, two speed LEDs, two link LEDs, two PVDM LEDs, two AIM LEDs,
system status LED (SYS OK), system activity (SYS ACT) LED, inline power LED, and CF LED. The
back panel has the power inlet and on/off switch.
The front panel contains the following:
• (1) VIC slot
• (2) HWIC/WIC/VIC slot 0
• (3) WIC/VIC slot
• (4) HWIC/WIC/VIC slot 1
• (5) Console port
• (6) FE ports
• (7) System status and activity LEDs
• (8) Inline power LED
• (9) USB port
• (10) FE LEDs
• (11) Auxiliary port
• (12) CF LED
• (13) CF drive
The rear panel contains the following:
• (1) Power inlet
• (2) Power switch
• (3) Ground connector
Table 5 provides more detailed information conveyed by the LEDs on the front panel of the router:
1. The security policy covers the configuration in which one AIM card is used.
Table 5 Cisco 2801 Front Panel Indicators
Name State Description
System OK Solid Green
Blinking Green
Router has successfully booted up and the software is
functional.
Booting or in ROM monitor (ROMMON) mode.
Inline Power Solid Green
Amber
Off
Inline power supply is working properly.
Inline power failure.
Inline power supply is not present.
System Activity Solid Green
Blinking Green
Off
System is actively transferring packets.
System is servicing interrupts.
No interrupts or packet transfer occurring.

Cisco 1841 Specifications

General

Flash memory	32 MB
Internal memory	128 MB
Product color	Black, Blue, Stainless steel
Rack capacity	1U
LED indicators	Yes
Storage temperature (T-T)	-25 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Cabling technology	10/100Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	2
Firewall security	Cisco IOS
Security algorithms	128-bit AES, 192-bit AES, 256-bit AES, 3DES, DES
Dual-band	No

Weight and Dimensions

Depth	274 mm
Width	343 mm
Height	47.5 mm
Weight	2800 g
