Cisco 3600 Series Configuration Guide

Configure Voice over IP for Microsoft NetMeeting
Configuring Voice over IP for the Cisco 3600 Series VC-37
Configure a Trunk Connection
To configure virtual trunk connections in a VoIP network, use the following commands beginning in
global configuration mode:
Note This configuration must be performed on both end routers for the trunk connection to be
established.
Configure Voice over IP for Microsoft NetMeeting
Voice over IP can be used with Microsoft NetMeeting (Version 2.x) when the Cisco 3600 or Cisco
2600 series router is used as the voice gateway. Use the latest version of DirectX drivers from
Microsoft on your PC to improve the voice quality of NetMeeting.
Configure Voice over IP to Support Microsoft NetMeeting
To configure Voice over IP to support NetMeeting, create a VoIP peer that contains the following
information:
• Session Target—IP address or DNS name of the PC running NetMeeting
• CODEC—g711ulaw or g711alaw
Step Command Purpose
1 dial-peer voice number pots Enter dial-peer configuration mode and define a tag
number for a POTS dial peer.
2 destination-pattern [+]string Specify the telephone number associated with the
POTS dial peer.
3 port slot-number/subunit-number/port Associate the POTS dial peer with a specific voice
port on the Cisco end router.
4 dial-peer voice number voip Define a tag number for a VoIP dial peer.
5 session target ipv4:destination-address Identify the IP address of the appropriate port on
the destination end router.
6 destination-pattern [+]string Identify the destination pattern (telephone number)
of the VoIP dial peer call leg on the destination end
router.
7 exit Exit dial-peer configuration mode.
8 configure terminal Enter global configuration mode.
9 voice-port
slot-number/sub-unit-number/port
Enter voice-port configuration mode.
10 connection trunk string Specify a straight tie-line connection (virtual trunk
connection). The string argument refers to the
destination pattern (telephone number) configured
for the destination VoIP dial peer. The value you
configure for the connection trunk command must
exactly match the value configured for the VoIP
dial peer.

Cisco 3600 Series Specifications

General

Operating System	Cisco IOS
Series	3600
Type	Modular Router
Interfaces	Ethernet, Fast Ethernet, Serial, ISDN
Routing Protocols	RIP, OSPF, EIGRP, BGP, IS-IS
Redundancy	Optional redundant power supply
Management	CLI, SNMP, Telnet
Weight	Varies depending on the specific model
Power Supply	AC or DC, optional redundant power supply
