Cisco 3640 Series Router-PBX Interoperability: VIC 2BRI-NT/TE card to Alcatel 4400 PBX with BRI ISDN QSIG Signaling
Page 6
Cisco 3640 Series Router Configuration
The following is the configuration of the Cisco 3640 series router connected to the Alcatel 4400 ISDN BRI
ISDN QSIG signaling interface.
• Cisco 3640 Series Router Version Information
• Cisco 3640 Series Router Sample Configuration
Cisco 3640 Series Router Version Information
• Cisco IOS™ (C3640-JS-M), Version 12.2(1a).
• Cisco 3640 (R4700) processor (revision 0x00) with 59392K/6144K bytes of f memory.
3640_B#
3640_B#sho ver
Cisco Internetwork Operating System Software
IOS (tm) 3600 Software (C3640-JS-M), Version 12.2(1a), RELEASE SOFTWARE (fc1)
Copyright (c) 1986-2001 by cisco Systems, Inc.
Compiled Sat 26-May-01 02:40 by pwade
Image text-base: 0x60008950, data-base: 0x61492000
ROM: System Bootstrap, Version 11.1(7)AX [kuong (7)AX], EARLY DEPLOYMENT RELEASE SOFTWARE
(fc2)
3640_B uptime is 1 hour, 21 minutes
System returned to ROM by power-on
System image file is "flash:c3640-js-mz.122-1a.bin"
cisco 3640 (R4700) processor (revision 0x00) with 59392K/6144K bytes of memory.
Processor board ID 05247801
R4700 CPU at 100Mhz, Implementation 33, Rev 1.0
Channelized E1, Version 1.0.
Bridging software.
X.25 software, Version 3.0.0.
SuperLAT software (copyright 1990 by Meridian Technology Corp).
TN3270 Emulation software.
Primary Rate ISDN software, Version 1.1.
Basic Rate ISDN software, Version 1.1.
2 Ethernet/IEEE 802.3 interface(s)
31 Serial network interface(s)
2 ISDN Basic Rate interface(s)
2 Channelized E1/PRI port(s)
2 Voice FXS interface(s)
4 Voice NT or TE BRI interface(s)
DRAM configuration is 64 bits wide with parity disabled.
125K bytes of non-volatile configuration memory.
16384K bytes of processor board System flash (Read/Write)
Configuration register is 0x2102
3640_B#
3640_B#
Cisco 3640 Series Router Sample Configuration
The following is a sample configuration of the Cisco 3640 series router directly connected to Alcatel 4400
PBX, slot 3 ISDN PRI interface.
3640_B#
3640_B#sho diag
Slot 0:
Combo 2E, 2W Port adapter, 4 ports
Port adapter is analyzed
