12 Cisco 4000 Series Rack-Mount and Wall-Mount Installation
Overview of Telco Rack-Mounting and Wall-Mounting
Figure 12 Rack-Mount Bracket Insertion
Overview of Telco Rack-Mounting and Wall-Mounting
The same brackets are used for both telco rack-mounting and for wall-mounting. (See Figure 13.)
After the brackets have been installed into either the old, tab-mount version of the chassis, or the new
screw-mount version of the chassis, the chassis is then ready for mounting in either a telco rack or
on a wall.
Figure 13 Telco Rack-Mount or Wall-Mount Bracket
H5961
cisco Systems
Cisco 4000
M3
machine
screw
Equipment
rack
Bracket
extenders
10-32
machine
screws
H5963
