Cisco 4000 Series Rack-Mount and Wall-Mount Installation 9
Mounting the Chassis in a Standard Rack
Figure 7 Rack-Mount Bracket Insertion in an Old Version of the Chassis
Figure 8 Standard Rack-Mount Bracket Installation in an Old Version of the Chassis
Rear of the chassis
H5977
Rack-mount
bracket
M3 machine screw
Front of the
chassis shell
H5979
Rack-mount bracket
M3 machine screw
Front of the chassis shell
10-32
machine
screws
