Cisco 7200 Series Port Adapter Hardware Configuration Guidelines
OL-3875-11
Chapter 1 Cisco 7200 Series Port Adapter Installation Requirements
Bandwidth and Bandwidth Point Requirements
Single-mode fiber, intermediate
reach
PA-SRP-OC12SMI High 300
4
0.40 MB —
Single-mode fiber, long reach PA-SRP-SML High 300
4
0.40 MB —
Single-mode fiber, extended
reach
PA-SRP-SMX High 300
4
0.40 MB —
Ethernet/Fast Ethernet/Gigabit Ethernet
2-port Fast Ethernet (FX) PA-2FE-FX High 400 2.4 MB —
1 port use of
2-port Fast Ethernet (RX)
PA-2FE-FX
5
High 200 2.4 MB —
2-port Fast Ethernet (TX) PA-2FE-TX High 400 2.4 MB —
1 port use of
2-port Fast Ethernet (TX)
PA-2FE-TX
5
High 200 2.4 MB —
14-port Ethernet switch
10/100BASETX
PA-12E/2FE High 300 0.17 MB —
8-port Ethernet 10BASET PA-8E Medium 80 0.40 MB —
5-port Ethernet 10BASEFL PA-5EFL 50 0.25 MB —
4-port Ethernet 10BASET PA-4E 40 —
2-port Fast Ethernet/ISL
100BASETX
PA-2FEISL-TX High 300 0.68 MB —
2-port Fast Ethernet/ISL
100BASEFX
PA-2FEISL-FX 300 0.68 MB —
1-port Fast Ethernet 100BASETX PA-FE-TX High 200 0.10 MB —
1-port Fast Ethernet 100BASEFX PA-FE-FX High 200 0.10 MB —
1-port 100VG-AnyLAN PA-100VG High 200 0.10 MB —
1-port dial shelf interconnect
6
PA-DSIC High 200 0.10 MB —
1-port full-duplex Gigabit
Ethernet
PA-GE Not
supported
400 0.24 MB —
I/O Controllers
1-port Gigabit Ethernet plus
Ethernet I/O controller
C7200-I/O-GE+E
7
High 400 0.11 MB
2-port Fast Ethernet/Ethernet
I/O controller
C7200-I/O-2FE/E
8
High 400 0.10 MB —
1 port use of
2-port Fast Ethernet/Ethernet
I/O controller
C7200-I/O-2FE/E
9
High 200 0.10 MB —
1-port Fast Ethernet I/O
controller (2 connectors: RJ-45
and MII)
C7200-I/O-FE
10
High 200 0.10 MB —
Table 1-6 Bandwidth, Bandwidth Points, and Processor Memory Requirements (continued)
Port Adapter Type Product Number
Bandwidth
Resource
Requirement
Bandwidth
Points
Processor
Memory
Required
1
Additional
Requirements
To Next Page
