Table 1. Illuminated Buttons
Button Line Status
Off (dark) Line available
Green, steady Line in use
Red, steady Line in use by someone else
Amber, flashing Line ringing
Green, flashing Call is on hold
These capabilities provide features that are similar to typical Direct Station Selection/Busy Lamp Field (DSS/BLF)
modules but are not intended to be directly comperable to traditional DSS/BLF modules. The Cisco Unified IP Phone
Expansion Module 7916 is not an operator or attendant console. The primary function of this module is to provide the
Cisco Unified IP Phone 7962G, 7965G, and 7975G models with additional keys for features such as speed dial or
directory numbers. The illuminated buttons provide ease of line status, making the Cisco Unified IP Phone
Expansion Module 7916 an ideal call-coverage tool.
The two illuminated page buttons beneath the display of the Cisco Unified IP Phone Expansion Module 7916 allow
you to shift between the first and second pages of 12 buttons, providing access to all 24 keys, 12 at a time (Table 2).
Table 3 lists the features of the Cisco Unified IP Phone Expansion Module 7916.
Table 2. Illuminated Page Buttons
Button Page Status
Off (dark) Page not in focus
Green, steady Page in focus
Amber, flashing Page not in focus with one or more alerting or on-hold calls present on page
Table 3. Features and Description
Feature Description
Graphical display 4.3” graphical (TFT) color display, 16-bit color depth, 480 x 272 effective pixel resolution, with backlight.
The display also supports localization requiring double-byte Unicode encoding for fonts.
Directory-number and feature buttons The module has 12 physical buttons (24 with page key).
Page buttons The two Page buttons are used to access each page of 12 buttons and provide phone status.
Sleep or inactivity mode When Cisco Unified IP Phone 7965G or 7975G models are in power-saving sleep or inactivity mode, the
Cisco Unified IP Phone Expansion Module 7916 is also in sleep or inactivity mode. In addition to the
Display button, any button on the Cisco Unified IP Phone Expansion Module 7916 that is pressed will
cause the displays to awaken. The inactivity period is configured by the system administrator.
Software Requirements
Table 4 lists the software requirements for the Cisco Unified IP Phone Expansion Module 7916.
Table 4. Cisco Unified IP Phone Expansion Module 7916 Software Requirements
Specification Description
Phone software requirements 8.3(5) and later
Call-control compatibility Cisco Unified Communications Manager 4.2(3) SR3a, 4.3(2), 5.1(3)b, 6.1(1), 7.0, 7.1 and later; Cisco Unified
Communications Manager Express 4.3/7.0 and later. Cisco Unified Survivable Remote Site Telephony
(Unified SRST) 4.1 (IOS 12.4.15T) and later.
Signaling protocols Skinny Client Control Protocol (SCCP) Software 8.3(5) and later
Session Initiated Protocol (SIP) Software 8.4(1) and later

Cisco 7916 Specifications

General

Brand	Cisco
Model	7916
Category	Telephone Accessories
Language	English
